Shapers Layout Square with Fin Placement Measurements.

Clear Poly-carbonate ‘transparent’ sheet which sits flat on surfboard blank
Giving accurate center-finding measurements from stringer to rail
Inches and MM Measurements
Measure Nose, tail and Midpoint exactly with the printed measurements on the square
Quick layout for Fin Positioning
Also used for tail measurements and fin settings.

The Shapers Layout Square – Dims

24″ in width | 609mm
12″ in Height | 304mm

How to use:

The Shapers Square ensures quick and accurate surfboard design measurements. Use the top of the Shapers Square for inches and the bottom for millimetres.

SURFBOARD DESIGN MEASUREMENTS

Surfboard’s Tail and Nose: Measure the surfboards wide points 12″ from the tip of the nose and 12″ from the tip of the tail. Place the bottom line (the 12” mark) on the Shapers Square at the tip of the blank, line up the centre line of the square with the stringer and make the 12″ width measurements for both the tail and nose.

Surfboard’s Width: Line up the Shapers Square Centre Line with the blanks stringer (ensure the entire centre line is aligned over the stringer). Keeping in line with the stringer, slide the square up and down the blank to mark out your surfboard design width’s.

Surfboard’s Fin Tow Angle Markings

(A) Measure and mark, on the stringer, the distance up from the tail that the fins will be set at. Move the Shapers Square up to the level (A) Line

(B) Align the Shapers Squares vertical (B) lines with the stringer in order to keep the measurements true. This will allow the Shapers Square to remain level while moving the square out towards the rail to mark your fins placements.

(C) Slide the Shapers Square right or left keeping (A) on the measure mark and (B) parallel to the stringer. Mark a dot at the 0” cut-out hole, at the distance you want from the rail to the trailing edge of the fin (known as the “Shapers Dot”).

(D) Use the 4” or 4.5” cut-out (depending on the base length of your fin) to mark the front tow angle of the fin.
